JOINT RSS-60-400 PG Pressacavo singolo, PG48, nero, IP66/IP67

The JOINT RSS-60-400 PG is a high-quality single cable entry seal designed for industrial, marine, offshore, and hazardous location applications. It provides reliable sealing and strain relief for cables with diameters from 4.0 to 40.0 mm. The one-piece design allows for quick and easy installation without the need for disassembly.

Advantages

This cable gland offers excellent protection against dust and water ingress with IP66/IP67 ratings, as well as NEMA 4X, 12, and 13 compliance. It is vibration resistant and can withstand pressures up to 0.3 MPa (3 bar). The polyamide body and EPDM rubber seal provide good chemical resistance against common chemicals, oils, and greases.

Suitable for

• Industrial machinery and equipment
• Marine and offshore installations
• Hazardous locations requiring ATEX/IECEx certification
• Control cabinets and junction boxes

Key specifications

• Product Type: Single Cable Entry Seal
• Material (Body): Polyamide (PA)
• Material (Rubber): EPDM Rubber
• Cable Diameter Range: 4.0 - 40.0 mm
• Number of Cables: 1
• Mounting Type: Threaded
• Thread Size: PG 48
• IP Rating: IP66/IP67
• NEMA Rating: NEMA 4X, 12, 13
• Temperature Range: -40°C to +80°C
• Color: Black
• Pressure Rating: Up to 0.3 MPa (3 bar)
• Vibration Resistance: Yes
• Chemical Resistance: Good against common chemicals, oils, and greases
• Certifications: UL/cUL, DNV, RMRS, IECEx, ATEX
• Installation Method: One-piece, direct installation

Recommendations

For optimal performance, ensure the cable diameter is within the specified range and the mounting hole is properly threaded. Always follow the manufacturer's installation guidelines.
