JUNG connettore a spina angolare per scatola potenziometro 65 WIS

Potentiometer sockets often sit in tight spaces where a straight plug makes cable routing awkward. The JUNG angled socket plug solves this by turning the connection 90 degrees, so the cable exits cleanly along the wall or panel instead of sticking straight out.

Who is it for

Electricians and installers working with JUNG potentiometer sockets in control systems, dimmers, or audio volume controls. If you need a reliable, low-profile connection that keeps cables tidy, this plug is built for that job.

Main features

• 90-degree angled design for space-saving cable routing
• 3-pole female connector with screw terminals for secure wiring
• Made from halogen-free thermoplastic in alpine white
• Compatible with JUNG potentiometer sockets (e.g., 65 POT)
• For cable mounting, IP20 rated

Specifications

• Product type: Angled plug
• Connector type: Female
• Number of poles: 3
• Connection method: Screw terminals
• Angle: 90 degrees
• Housing material: Thermoplastic
• Product colour: White
• Halogen-free: Yes
• Mounting type: Cable mount
• Application: For potentiometer sockets
• Compatibility: JUNG potentiometer sockets

Tips

Pair this angled plug with JUNG potentiometer sockets to keep installations neat in confined spaces. Always check the device's voltage and current ratings before connection.
