Klauke connettore faston femmina 4-6 mm² 750 V non isolato

The Klauke Flat Receptacle (spade terminal) is a high-quality, uninsulated crimp connector designed for reliable electrical connections in industrial, automotive, and general wiring applications. Manufactured from electrolytic copper with a tin-plated surface, it ensures excellent conductivity and corrosion resistance. Suitable for wire cross-sections from 4 to 6 mm², this terminal is rated for up to 750 V and can handle currents up to 41 A depending on wire size and application.

Advantages

• High-quality electrolytic copper (E-Cu) for optimal conductivity
• Tin-plated surface for corrosion protection
• Suitable for 4-6 mm² wire cross-section
• Rated voltage up to 750 V
• Current rating up to 41 A
• Wide operating temperature range: -40°C to +110°C
• RoHS compliant
• Conforms to DIN 46247 standard

Suitable for

• General electrical connections
• Control panels
• Automotive wiring
• Machinery and equipment
• Industrial maintenance

Key specifications

• Connector Type: Flat Receptacle (Spade Terminal)
• Insulation Type: Uninsulated
• Wire Cross-Section: 4 - 6 mm²
• Voltage Rating: 750 V
• Connection Method: Crimp
• Material: Electrolytic Copper (E-Cu)
• Surface Treatment: Tin-plated
• Terminal Width: 6.3 mm
• Terminal Thickness: 0.8 mm
• Contact Type: Female
• Max. Current: Up to 41 A
• Operating Temperature: -40°C to +110°C
• Color: Metallic (Silver-tone)
• Standard: DIN 46247
• Packaging Unit: 100 pieces

Recommendations

For best results, use with a suitable crimping tool designed for uninsulated terminals. Ensure proper wire stripping and crimping to achieve a secure and reliable connection. Always follow applicable electrical codes and safety guidelines.
