Klauke VHR25 capocorda ad anello, rame stagnato, 25 mm², foro per bullone M6, non isolato

The Klauke VHR25 is a high-quality ring terminal designed for reliable electrical connections in industrial, automotive, and electrical installations. Made from electrolytic copper with a tin-plated surface, it ensures excellent conductivity and corrosion resistance. Suitable for fine-stranded and multi-stranded copper conductors up to 25 mm², this uninsulated terminal features a 6.4 mm (M6) bolt hole diameter and is compatible with hexagonal and indent crimping methods.

Advantages

Tin-plated surface provides superior corrosion resistance and long-lasting performance. Electrolytic copper material ensures optimal electrical conductivity. Uninsulated design allows for versatile use in various applications. Compliant with relevant DIN standards for quality and safety.

Suitable for

• Industrial electrical installations
• Automotive wiring systems
• Electrical panel connections
• Power distribution systems

Key specifications

• Product Type: Ring Terminal
• Conductor Cross-Section: 25 mm²
• Bolt Hole Diameter: 6.4 mm (M6)
• Material: Electrolytic Copper (E-Cu)
• Surface Finish: Tin-plated
• Insulation Type: Uninsulated
• Overall Length: 31 mm
• Ring Width: 14 mm
• Barrel Inner Diameter: 7.2 mm
• Material Thickness: 1.5 mm
• Operating Temperature Range: -40°C to +120°C
• Maximum Voltage Rating: 1000 V
• RoHS Compliant: Yes

Recommendations

For optimal performance, use with appropriate crimping tools and ensure proper conductor preparation. Verify compatibility with your specific application requirements.
