Klauke VHR50 capocorda ad anello, 50 mm², foro per bullone M9, rame stagnato elettroliticamente, non isolato

The Klauke VHR50 is a high-quality ring cable lug designed for reliable and durable electrical connections. Manufactured from electrolytic copper (E-Cu) with an electro-tinned surface, it offers excellent corrosion resistance and conductivity. Suitable for fine-stranded, multi-stranded, and solid copper conductors (Classes 2, 5, 6), this uninsulated lug is ideal for crimping applications in industrial and commercial environments.

Advantages

Electro-tinned surface provides high corrosion resistance and long service life. Conforms to DIN 46235 for standardized quality. Compatible with hexagonal crimping tools for secure connections. Suitable for a wide range of conductor types, including fine-stranded and solid wires.

Suitable for

• Power distribution and control panels
• Industrial machinery and equipment
• Electrical installations requiring reliable ring terminals
• Automotive and marine applications

Key specifications

• Product Type: Ring Cable Lug
• Conductor Cross-Section: 50 mm²
• Bolt Hole Diameter: 9 mm (M9)
• Material: Electrolytic Copper (E-Cu)
• Surface Treatment: Electro-tinned
• Connection Method: Crimp
• Insulation: Uninsulated
• Standards Conformance: DIN 46235
• Temperature Resistance: Up to 120°C
• RoHS Compliant: Yes
• Halogen-Free: Yes
• Country of Origin: Germany

Recommendations

For optimal performance, use with appropriate hexagonal crimping tools. Ensure conductor stripping length matches barrel depth. Always follow manufacturer guidelines for crimping force and die selection.
