König & Meyer perno TV 24516-000-00 grezzo (24516-000-00)

Terminating a coaxial cable for TV or radio often requires a connector that is reliable and easy to install. The König & Meyer TV-Zapfen 24516-000-00 blank is a male coaxial connector with a 75 Ohm impedance, suitable for terrestrial TV, cable TV, and FM radio applications. Its nickel-plated brass body and screw/clamp shield connection ensure a secure fit on coaxial cables up to 7 mm in diameter.

Who is it for

Installers and DIY enthusiasts who need a dependable connector for coaxial cable terminations in TV and radio setups.

Main features

• Male TV coaxial connector (IEC 60169-2)
• 75 Ohm impedance for standard TV and radio signals
• Nickel-plated brass housing for durability
• Solder connection for inner conductor, screw/clamp for shield
• Supports cables up to 7 mm outer diameter

Specifications

• Connector type: TV coaxial (IEC 60169-2)
• Gender: Male
• Impedance: 75 Ohm
• Frequency range: 0 - 1000 MHz
• Housing material: Nickel-plated brass
• Connection method: Solder (inner), screw/clamp (shield)
• Cable compatibility: up to 7 mm outer diameter
• Colour: Silver

Tips

Ensure the cable is properly stripped and the shield is evenly clamped to maintain signal integrity.
