MEAN WELL MDR-10-24 alimentatore per guida DIN 10W 24V DC, 0,42A

Compact DIN rail power supply delivering stable 24V DC output with 10W power, ideal for industrial automation and control systems. Its slim plastic housing saves space on TS-35 rails, while free air convection cooling ensures silent operation.

Advantages

Wide input voltage range (85-264VAC) allows use in various electrical environments. Built-in protections against short circuit, overload, and overvoltage safeguard connected equipment. High efficiency of 82% reduces energy waste and heat generation.

Suitable for

• Industrial control panels
• Building automation systems
• Sensor and actuator power
• Small machinery and equipment

Key specifications

• Output: 24V DC, 0.42A, 10.08W
• Input: 85-264VAC / 120-370VDC
• Efficiency: 82%
• Mounting: DIN rail TS-35/7.5 or 15
• Protections: short circuit, overload, overvoltage
• Operating temperature: -20 to +70°C
• Isolation: 3kVAC input/output
• Certifications: UL508, TUV EN60950-1, CE

Recommendations

For reliable 24V power in tight spaces, the MDR-10-24 is an excellent choice. Ensure adequate ventilation and verify DIN rail compatibility before installation.
