MENNEKES 636A spina CEE 16A 3 poli 20-25V IP44 blu

Industrial and commercial environments often demand reliable power connections that can withstand moisture, dust, and mechanical stress. The MENNEKES 636A CEE plug addresses this need with a robust design that ensures safe and consistent electrical connections for low-voltage applications.

Who is it for

This plug is intended for electricians, maintenance technicians, and facility managers who require a dependable, splash-proof connector for portable equipment, generators, or temporary power distribution in workshops, construction sites, and outdoor events.

Main features

• 16 A current rating with 3-pole (2P+E) configuration for single-phase low-voltage circuits.
• Voltage range of 20-25 V, suitable for specialized low-voltage systems.
• IP44 ingress protection against splashing water and solid objects larger than 1 mm.
• Straight plug design with screw terminals for secure, vibration-resistant wiring.
• Blue polyamide housing for high durability and easy identification.
• Earth contact position at 12h per IEC 60309 standard.

Specifications

• Current rating: 16 A
• Number of poles: 3 (2P+E)
• Voltage range: 20-25 V
• IP rating: IP44
• Standard: IEC 60309
• Connection technology: Screw terminals
• Cable entry: Cable gland
• Housing material: Polyamide
• Colour: Blue
• Earth contact position: 12h
• Frequency: 50/60 Hz
• Contact material: Nickel-plated brass
• Operating temperature: -25°C to +40°C
• Terminal cross-section: 1.5 - 4 mm²
• Flammability rating: UL94 V2
• Glow wire test: 850 °C

Tips

Ensure the cable diameter matches the gland size to maintain the IP44 protection. Use a suitable screwdriver to tighten terminals to the recommended torque for reliable contact.
