METZ CONNECT 11070013 modulo relè 24 V DC 1 CO bianco

This relay module from METZ CONNECT stands out with its compact DIN rail mount design and a single changeover contact rated for 6 A at 250 V AC. The 24 V DC coil consumes only 0.2 W, making it an energy-efficient choice for control cabinet applications.

Highlights

• 1 changeover contact (SPDT) with AgNi contact material for reliable switching
• Coil voltage 24 V DC, rated switching current 6 A at 250 V AC
• DIN rail mounting (TS 35) with screw terminals for solid or stranded wires up to 2.5 mm²
• Wide operating temperature range from -25 °C to +70 °C
• White housing for clear identification in installations

In daily use

The module is designed for straightforward integration into industrial control systems. Screw terminals accept solid conductors from 0.2 to 2.5 mm², and the relay provides a mechanical life of 20 million switching cycles, reducing maintenance frequency in high-cycle applications.

Full specifications

• Product type: Relay Module
• Contact configuration: 1 CO (SPDT)
• Coil voltage: 24 V DC
• Rated switching voltage: 250 V AC
• Rated switching current: 6 A
• Contact material: AgNi
• Mounting type: DIN rail (TS 35)
• Connection type: Screw terminals
• Operating temperature: -25 °C to +70 °C
• Coil power: 0.2 W
• Insulation voltage (coil/contact): 4 kV AC
• Mechanical life: 20 x 10^6 cycles
• Electrical life: 100 x 10^3 cycles (6 A, 250 V AC, resistive)
• Terminal wire size (solid): 0.2 - 2.5 mm²
• Terminal wire size (stranded with ferrule): 0.2 - 2.5 mm²

Final note

With approvals from UL, cUL, VDE, EAC, and CE, this relay module meets international standards for industrial use.
