Mini-PC ZOTAC ZBOX MAGNUS ONE EU27507TC Barebone — Intel Core Ultra 7 265, NVIDIA GeForce RTX 5070 Ti 16GB

ZOTAC ZBOX MAGNUS ONE EU27507TC (ZBOX-EU27507TC-BE) is an 8.48-litre mini PC with desktop components, supplied as a barebone: the desktop Intel Core Ultra 7 265 processor, the ZOTAC GAMING GeForce RTX 5070 Ti 16GB GDDR7 graphics card and an integrated 650W power supply are already installed. Memory, storage and an operating system are not included, so you choose DDR5 SO-DIMM modules, M.2 NVMe or 2.5-inch SATA drives and the operating system yourself. According to ZOTAC, tool-less access makes it easy to upgrade the memory, storage or even the graphics card.

Specifications

• Processor: Intel Core Ultra 7 265 (20 cores, 20 threads, 2.4 GHz up to 5.3 GHz, 30 MB cache)
• Graphics card: ZOTAC GAMING GeForce RTX 5070 Ti 16GB GDDR7 (graphics card compatibility: up to 300W, dual-slot, up to 245 mm long)
• Memory: not included; 2 × DDR5 SO-DIMM slots, up to 96GB
• Storage: not included; 1 × M.2 NVMe slot (PCIe 5.0 x4), 1 × M.2 NVMe slot (PCIe 4.0 x4, 2242/2280), 1 × 2.5-inch SATA III bay
• Operating system: not included
• Display outputs: 3 × DisplayPort 2.1b with UHBR20, 1 × HDMI (up to 4K 480Hz HDR or 8K 120Hz HDR with DSC), 1 × HDMI 2.0 (integrated), DisplayPort via Thunderbolt 4 (integrated); up to 4 displays cloned or 6 extended
• Front ports: UHS-II 3-in-1 card reader (SD/SDHC/SDXC), 2 × USB 3.0 (1 × Type-C)
• Rear ports: 1 × Thunderbolt 4, 4 × USB 3.2 Gen 2, 2 × USB 3.0, 1 × 5GbE LAN (10/100/1000/2500/5000), 1 × 1GbE LAN, dual Wi-Fi antenna connector
• Wireless: Wi-Fi 7 (802.11be), Bluetooth 5.4
• Audio: 8-channel digital audio via HDMI, analogue stereo in/out
• Power supply: integrated, 650W
• Dimensions: 270.5 × 126 × 249 mm
