MITON MT-P203-B scatola di derivazione, da parete, ABS, grigia, IP44, 80x80x40mm

The MITON MT-P203-B is a high-quality surface-mounted junction box designed for reliable electrical installations. Manufactured from durable ABS plastic with a grey (RAL 7035) finish, this enclosure offers excellent protection and longevity. With an IP44 rating, it is suitable for indoor and outdoor use, safeguarding against dust ingress and water splashes.

Advantages

Robust ABS construction ensures impact resistance (IK07) and self-extinguishing properties (UL94-HB equivalent). The screw-on lid with 4 screws provides secure closure, while smooth walls allow for custom cable entry drilling. Halogen-free and glow wire tested at 650°C, it meets high safety standards.

Suitable for

• Electrical junction and connection boxes in residential, commercial, and industrial settings
• Surface-mounted installations where IP44 protection is required
• Custom cable entry applications

Key specifications

• Product Type: Junction Box
• Mounting Type: Surface-mounted
• Material: ABS Plastic
• Colour: Grey (RAL 7035)
• Ingress Protection: IP44
• External Dimensions (L x W x H): 80 x 80 x 40 mm
• Internal Depth: Approx. 35 mm
• Lid Fastening: 4x Screw-on
• Operating Temperature: -25°C to +60°C
• Impact Resistance: IK07
• Flammability Rating: Self-extinguishing (UL94-HB equivalent)
• Glow Wire Test: 650°C
• Halogen-Free: Yes
• Certifications: CE

Recommendations

For optimal installation, use appropriate cable glands and ensure proper sealing of cable entries to maintain IP44 protection. This junction box is ideal for new installations or retrofitting in existing systems.
