Modulo convertitore DC-DC MEAN WELL DPAN02A-15 2W 5V a 15V SIP4

In industrial control cabinets, sensors and analog circuits often need a stable 15V rail from a 5V logic supply. The MEAN WELL DPAN02A-15 is a compact 2W DC-DC converter module that steps up 5V DC to a regulated 15V DC output. Its SIP4 package fits directly into standard through-hole footprints, making it easy to integrate into PCBs for automation, instrumentation, and telecommunication equipment.

Key specifications

• Input voltage: 4.5–5.5 V DC (nominal 5 V DC)
• Output voltage: 15 V DC
• Output current: 134 mA (max)
• Output power: 2 W
• Isolation voltage: 1500 V DC
• Efficiency: 80% (typical)
• Operating temperature: -40 to +85 °C
• Ripple & noise: 100 mVp-p (max)
• Line regulation: ±0.5%
• Load regulation: ±1.0%
• Short circuit protection: continuous, auto-recovery
• Package: SIP4, through-hole mounting

Why choose it

The DPAN02A-15 provides reliable galvanic isolation between input and output, protecting sensitive circuits from ground loops and noise. Its wide operating temperature range and built-in short-circuit protection ensure long-term stability in demanding environments. The unregulated input design simplifies circuit requirements, while the regulated output maintains consistent voltage for downstream components.

Ideal use cases

• Industrial sensors and transmitters
• Data acquisition systems
• Telecom and networking equipment
• Portable battery-powered devices
• Distributed power architectures

Good to know

The module is designed for PCB mounting and requires external input and output capacitors for optimal performance. It is not a standalone desktop adapter; ensure proper heat dissipation in high-temperature applications. Compliance with international safety standards makes it suitable for global use.
