Modulo presa VGA + RCA Bachmann 917.058 connessione audio-video

The Bachmann 917.058 socket-outlet combines VGA and RCA connectors in a compact module designed for installation in desks, panels, or wall boxes. It provides reliable audio-visual connectivity for computers, projectors, monitors and AV equipment. The unit includes a side-mounted 90° power outlet design intended to align with power strips that have a lateral 90° outlet.

Advantages

The module integrates both VGA and RCA interfaces to support video and analogue audio connections in one unit, simplifying cable routing and installation. Its side 90° outlet compatibility reduces cable strain in confined installations and helps maintain a low-profile setup. Built by Bachmann and bearing MPN 917.058, it is suitable for residential and commercial AV environments where standard VGA and RCA connectivity is required.

Suitable for

• Connecting PCs or laptops to projectors and monitors via VGA
• Connecting analogue audio or composite video devices using RCA
• Integration into desks, conference tables, or AV furniture

Key specifications

• Manufacturer: Bachmann
• Model / MPN: 917.058
• EAN: 4016514034857
• Connector types: VGA and RCA
• Side-mounted 90° power outlet compatibility (compatible only with power strips featuring a lateral 90° outlet)

How to use

Install the module into the intended panel cutout or furniture mounting bracket following Bachmann installation guidelines. Connect the VGA cable from your computer or video source to the VGA socket and plug RCA cables for audio or composite video as required. Ensure the power strip used for the side 90° outlet matches the lateral 90° configuration before connecting to avoid misalignment.

Recommendations

Use appropriate cable shielding and secure connectors to maintain signal quality; verify that the power strip has a lateral 90° outlet to ensure mechanical compatibility with the side-mounted outlet design.
