Morsetto a vite PAWBOL E.4031P a 12 poli 2,5mm² 450V 24A poliammide trasparente

For installations demanding high-density wiring with instant visual assurance, the PAWBOL E.4031P sets itself apart through its transparent polyamide housing. Unlike opaque terminal blocks that hide conductor seating, this 12-pole screw terminal block lets you confirm every connection at a glance—reducing commissioning errors and speeding up troubleshooting in control panels, junction boxes, and machinery.

Highlights

• 12 independent screw terminals for multi-conductor connections
• Accepts conductors up to 2.5 mm² (AWG 14)
• Rated for 450 V and 24 A – suitable for power and control circuits
• Transparent PA housing for easy inspection
• Galvanized steel screws resist corrosion
• Operating temperature range -25°C to +110°C
• UL94 V-2 flammability rating
• CE and RoHS certified

In daily use

Installers appreciate the free-hanging or screw-mountable design that adapts to panels, junction boxes, or DIN rail-less setups. The brass conductor material ensures low contact resistance, while the polyamide insulation provides mechanical strength and thermal stability. Each pole is clearly numbered, simplifying wiring and troubleshooting.

Full specifications

• Brand: PAWBOL
• Model: E.4031P
• MPN: E.4031P
• EAN: 5908289623222
• Product type: Terminal block
• Connection type: Screw terminal
• Number of poles: 12
• Max wire cross-section: 2.5 mm²
• Rated voltage: 450 V
• Rated current: 24 A
• Insulation material: Polyamide (PA)
• Conductor material: Brass
• Screw material: Galvanized steel
• Colour: Transparent
• Temperature resistance: Up to 110°C
• Flammability rating: UL94 V-2
• Mounting type: Free-hanging / screw-mountable

Final note

With its transparent body, numbered poles, and robust 450V/24A rating, the E.4031P is a practical choice for electricians who value both safety and efficiency in dense wiring environments.
