MSI PRO DP10 A14MG-017XAT Mini PC Intel Core i7-14700

The MSI PRO DP10 A14MG-017XAT is a compact and powerful mini PC designed for professional environments. Powered by an Intel Core i7-14700 processor with 20 cores and 28 threads, it delivers exceptional performance for multitasking, office applications, and content creation. With 16GB DDR4 RAM and a 1TB NVMe PCIe Gen4 SSD, this system ensures fast boot times and ample storage. The integrated Intel UHD Graphics 770 supports up to three displays via HDMI 2.1, DisplayPort 1.4, and D-Sub (VGA). Connectivity includes Wi-Fi 6E, Bluetooth 5.3, and 2.5 Gigabit Ethernet. The mini PC comes without an operating system, allowing you to install your preferred OS.

Advantages

Compact form factor saves desk space while delivering desktop-grade performance. The latest Intel Core i7-14700 processor provides high efficiency for demanding tasks. Dual storage options (M.2 PCIe Gen4 and 2.5-inch SATA) offer flexibility. Comprehensive I/O ports including USB-C and USB-A ensure compatibility with modern peripherals.

Suitable for

• Office productivity and multitasking
• Digital signage and kiosks
• Home entertainment and media centers
• Light content creation and photo editing

Key specifications

• Processor: Intel Core i7-14700 (20 cores, 28 threads, up to 5.5 GHz)
• Graphics: Intel UHD Graphics 770
• RAM: 16GB DDR4 3200MHz (max 64GB)
• Storage: 1TB NVMe PCIe Gen4 SSD
• Wireless: Wi-Fi 6E (802.11ax), Bluetooth 5.3
• Wired: 2.5 Gigabit Ethernet
• Video Outputs: 1x HDMI 2.1, 1x DisplayPort 1.4, 1x D-Sub (VGA)
• Front Ports: 1x USB 3.2 Gen 2 Type-C, 1x USB 3.2 Gen 2 Type-A
• Rear Ports: 2x USB 3.2 Gen 1 Type-A, 2x USB 2.0 Type-A
• Audio: 1x Mic-in, 1x Headphone-out (front)
• Power: 120W AC Adapter
• Form Factor: Mini PC
• Security: Kensington Lock, TPM 2.0

Recommendations

Ideal for businesses seeking a reliable, space-saving computing solution. The absence of an OS allows customization for enterprise deployment. Pair with MSI's commercial monitors for a complete workspace.
