BVV-P cavo piatto in PVC bianco 2x2,5 mm², rotolo da 25 m, 450/750 V

Rated for 450/750 V and built with solid copper conductors, this BVV-P flat cable delivers dependable fixed-installation power wiring in a clean white PVC jacket. The 2×2.5 mm² configuration supports standard branch circuits, while the flat profile keeps runs tidy along walls, baseboards, and cable trays.

Overview

The BVV-P 2×2.5 white cable is a two-core flat electrical cable with solid copper conductors and a durable PVC insulation and sheath. Supplied as a 25-meter coil, it is intended for fixed indoor installations where a non-propagating flame rating and a wide operating temperature range are required. The white sheath blends discreetly into light-coloured interiors and simplifies circuit identification in multi-cable installations.

What stands out

• Solid copper conductors ensure stable, low-resistance power delivery over long runs.
• Flat construction reduces bulk and allows neat routing in confined spaces.
• PVC insulation and sheath provide good mechanical protection and resistance to common chemicals.
• Non-flame propagating (Category B) performance enhances safety in building wiring.
• Wide ambient temperature range from -50 °C to +50 °C supports use in unheated spaces.

Technical details

• Cable type: BVV-P (VVG-P equivalent)
• Number of cores: 2
• Conductor cross-section: 2.5 mm²
• Conductor material: Copper (solid / single-wire)
• Insulation: PVC
• Sheath: PVC, white
• Rated voltage Uo/U: 450/750 V
• Max. conductor operating temperature: +70 °C
• Ambient operating temperature: -50 °C to +50 °C
• Outer cable dimensions (approx.): 4.5 x 7.5 mm
• Fire performance: Non-flame propagating (Category B)
• Standard compliance: GOST 31996-2012 (or equivalent regional standard)
• Packaging: Coil / roll
• Halogen-free: No
• UV resistance: No

Our verdict

A reliable and tidy solution for fixed indoor power wiring, offering solid copper performance and a discreet white finish in a convenient 25-meter coil.
