JOINT RSS-60-200 PG Kit di giunzione a caldo per cavi 0,6/1 kV, 4 conduttori, 60-200 mm²

When underground or submerged cable connections demand uncompromising reliability, the JOINT RSS-60-200 PG steps beyond ordinary joint kits. Engineered for 0.6/1 kV low-voltage networks, this heat shrinkable joint kit handles 4-core plastic insulated cables with conductor cross-sections from 60 to 200 mm², supporting both copper and aluminum conductors. Its integrated sealant and UV-resistant, halogen-free design ensure long-term performance in the harshest environments.

Highlights

• Wide conductor range: 60–200 mm², 4-core configuration
• Compatible with XLPE, EPR, PVC, and PE insulated cables
• Integrated water sealing for underground and submerged use
• UV resistant and halogen-free for outdoor and indoor safety
• Meets IEC 60502-4 standards
• Includes heat shrink tubes, sealant, cleaning wipes, and instructions

In daily use

Installers appreciate the straightforward process: clean the cable ends, slide on the heat shrink components, apply heat evenly, and the joint forms a robust, moisture-proof seal. The integrated earth connection system simplifies grounding, while the flexible operating temperature range from -20°C to +90°C ensures reliable operation in diverse climates. Whether repairing a damaged cable or extending a network, this kit delivers consistent, professional results.

Full specifications

• Product type: Heat shrinkable cable joint kit
• Voltage rating: 0.6/1 kV
• Number of cores: 4
• Conductor cross-section: 60–200 mm²
• Cable type: Plastic insulated (XLPE, EPR)
• Conductor material: Copper, Aluminum
• Joint technology: Heat shrink
• Application environment: Underground, submerged, outdoor, indoor
• Water sealing: Integrated sealant
• UV resistant: Yes
• Halogen-free: Yes
• Standard compliance: IEC 60502-4
• Sheath material compatibility: PVC, PE
• Earth connection: Integrated
• Operating temperature: -20°C to +90°C
• Insulation material compatibility: XLPE, EPR
• Kit contents: Heat shrink tubes, sealant, cleaning wipes, instructions

Final note

Built to last, the JOINT RSS-60-200 PG provides a dependable, long-term solution for demanding cable jointing tasks.
