Noark Ex9DS-F 106194 presa modulare, guida DIN TH-35, 2,5 m, Schuko (tipo F), 16 A, 250 V, bianco/grigio

The Noark Ex9DS-F 106194 is a high-quality modular socket designed for installation in Noark Ex9DS-F distribution boards. It features a Schuko (Type F) outlet with 2 poles plus protective earth (2P+PE), rated for 16A and 250V AC. The socket is mounted on a DIN rail TH-35 and occupies 2.5 modular spaces. Its robust construction includes self-extinguishing thermoplastic material and screw terminals for secure wiring.

Advantages

This socket offers reliable performance and easy installation in standard distribution boards. The screw terminals accommodate rigid conductors up to 4 mm² and flexible conductors up to 2.5 mm². With IP20 front protection and IP40 terminal protection, it ensures safety in indoor environments. The white/grey colour blends seamlessly with most electrical panels.

Suitable for

• Residential and commercial electrical distribution systems
• Installation in Noark Ex9DS-F series distribution boards
• Power supply for general electrical devices requiring Schuko (Type F) plugs

Key specifications

• Socket Type: Schuko (Type F)
• Number of Modules: 2.5 M
• Rated Voltage: 250 V AC
• Rated Current: 16 A
• Frequency: 50/60 Hz
• Mounting Type: DIN Rail TH-35
• Number of Poles: 2P+PE
• Terminal Type: Screw terminals
• Max. Conductor Size (Rigid): 4 mm²
• Max. Conductor Size (Flexible): 2.5 mm²
• IP Protection Rating (Front): IP20
• IP Protection Rating (Terminals): IP40
• Material: Self-extinguishing thermoplastic
• Colour: White/Grey
• Compatibility: Noark Ex9DS-F distribution boards
• Standards: EN 60884-1
• Operating Temperature: -25°C to +50°C

Recommendations

For optimal performance, ensure the socket is installed by a qualified electrician and used within its rated specifications. Always follow local electrical codes and regulations.
