NOARK quadro di distribuzione in plastica NT 12M 1X N+PE IP65 IK07

Engineered for demanding environments, this distribution box delivers IP65 protection against dust and water jets, combined with IK07 impact resistance. The NOARK NT 12M houses up to 12 modules in a single row, with a transparent door for easy inspection and a 180° opening angle for convenient access during installation and maintenance.

Overview

The NOARK NT 12M is a surface-mounted plastic distribution box crafted from UV-resistant ABS, ensuring long-term durability even when exposed to sunlight. It includes a DIN rail, one neutral terminal block, and one protective earth terminal block, providing a complete solution for electrical distribution in residential, commercial, and light industrial applications. The grey base with transparent door offers a modern appearance while allowing clear visibility of internal components.

What stands out

• High ingress protection: IP65 rating shields against dust and low-pressure water jets from any direction.
• Impact resistance: IK07 rating withstands mechanical impacts up to 2 joules, suitable for areas prone to knocks.
• Transparent door with 180° opening: Facilitates quick visual checks and easy wiring access.
• Complete mounting kit: Includes DIN rail, N and PE terminal blocks, and knockouts for cable entry.
• UV-stable ABS material: Prevents degradation from sunlight, maintaining integrity and appearance over time.

Technical details

• Number of modules: 12 (single row)
• Material: ABS plastic, grey base, transparent door
• Mounting type: Surface mounted
• Ingress protection: IP65
• Impact protection: IK07
• Rated insulation voltage: 500 V AC
• Glow wire test: 650 °C
• Operating temperature: -25°C to +60°C
• Standards compliance: IEC/EN 62208
• Terminal blocks included: 1x Neutral (N), 1x Protective Earth (PE)
• DIN rail included: Yes
• Cable entry: Knockouts
• UV resistance: Yes

Our verdict

The NOARK NT 12M distribution box combines robust protection with user-friendly features, making it a reliable choice for electricians and installers who need a durable, transparent enclosure for up to 12 modules. Its IP65 and IK07 ratings ensure performance in challenging conditions, while the included accessories simplify installation.
