Patch panel LogiLink NP0016A

The LogiLink NP0016A patch panel is a compact network distribution unit with 16 RJ-45 ports supporting Cat6 cable types. Designed for structured cabling in small office and home network environments, the grey metal housing provides a neat, functional appearance while meeting ISO/IEC 11801 E standards for reliable data transmission and signal integrity.

Advantages

The NP0016A offers a standardized 16-port layout that simplifies cable management and connection labeling. Compliance with ISO/IEC 11801 E ensures compatibility with Cat6 installations and predictable performance across compatible network hardware. The grey finish and compact form factor facilitate installation in racks or wall-mounted cabinets where space and visual integration are important.

Suitable for

• Small office local area network patching
• Home network distribution and consolidation
• Structured cabling closet or wall-mount cabinet installations
• Temporary or permanent network reconfiguration and testing

Key specifications

• Port count: 16 RJ-45 connectors
• Supported cable category: Cat6
• Housing colour: Grey
• Standards: ISO/IEC 11801 E compliant

How to use

Mount the patch panel into a compatible rack or cabinet location and secure it according to the rack or cabinet manufacturer’s instructions. Terminate each incoming horizontal cable onto the rear IDC punch-down or termination points, following Cat6 wiring color codes and ensuring tight, correct pair alignment. Connect active network devices or switches to the front RJ-45 ports using patch cords rated for Cat6 or higher. Label each port to match your cable plan for easier identification and future maintenance.

Recommendations

Use shielded or unshielded Cat6 cables consistent with your existing cabling scheme, avoid excessive cable bends and maintain recommended separation from power lines to preserve signal quality. For best results, test each link after termination with a certified cable tester and document port assignments.
