PHS-memory 48GB DDR5 ECC UDIMM 5600MHz PC5-44800E per DFI ATX RPS630-R680E/Q670E SP597569

When a DFI ATX RPS630-R680E/Q670E motherboard needs maximum memory capacity without sacrificing data integrity, this 48GB DDR5 ECC UDIMM module steps in. It eliminates memory errors that can crash servers and workstations, while delivering the bandwidth modern applications demand.

Who is it for

System builders and IT administrators deploying DFI ATX RPS630-R680E/Q670E platforms in server or workstation roles. It suits environments where uptime and data accuracy are non-negotiable, such as virtualization, database hosting, and compute-heavy tasks.

Main features

• 48GB capacity in a single module to maximize density per slot
• DDR5 technology with 5600MHz speed for faster data access
• ECC (Error-Correcting Code) detects and corrects single-bit errors
• Unbuffered DIMM (UDIMM) for lower latency in compatible boards
• Dual Rank (2Rx8) configuration for optimized performance
• 288-pin standard profile fits standard DIMM slots
• 1.1V operating voltage for energy efficiency
• CAS latency of CL46 for reliable timing

Specifications

• Memory capacity: 48 GB
• Memory type: DDR5
• Module type: UDIMM (Unbuffered DIMM)
• Error correction: ECC
• Memory speed: 5600 MHz
• PC classification: PC5-44800E
• Pin count: 288-pin
• Voltage: 1.1V
• CAS latency: CL46
• Rank: Dual Rank (2Rx8)
• Data transfer rate: 44.8 GB/s
• Form factor: Standard Profile DIMM
• Compatibility: DFI ATX RPS630-R680E/Q670E motherboard series
• Application: Server / Workstation
• Module configuration: 1 x 48GB

Tips

Verify that your motherboard's BIOS supports 48GB DDR5 ECC UDIMM modules. For dual-channel operation, install identical modules in pairs. Ensure the system is powered off and unplugged before installation.
