Pinza crimpatrice cimco Control Pliers 120 (modello 101650) per sezione cavo 0,5–6 mm²

cimco Control Pliers 120 (model 101650) are manual crimping pliers designed for crimping terminals and ferrules on conductors with cross-sections from 0.5 to 6 mm². The tool is suitable for precise compression of insulated and non-insulated terminals and for working with paper punchings and thin plastics where a narrow jaw is required. The pliers have a jaw depth of 30 mm and an overall length of 120 mm.

Advantages

The compact 120 mm length and 3 mm narrow jaw allow access in confined spaces. The pliers provide consistent crimps for reliable electrical contacts and are intended for use on both insulated and non-insulated terminals. Their manual design makes them suitable for maintenance, assembly and on-site electrical work.

Suitable for

• Crimping insulated and uninsulated terminals on 0.5–6 mm² conductors
• Electrical installation and repair work
• Service and factory assembly tasks requiring precise crimps
• Working with paper punchings and thin plastic parts where a 3 mm jaw fits

Key specifications

• Wire range: 0.5–6 mm²
• Jaw width (working tip): approx. 3 mm
• Jaw depth (maul depth): 30 mm
• Total length: 120 mm
• Tool type: manual crimping / control pliers

How to use

Insert the stripped conductor and the terminal into the jaw area aligned with the working tip, then squeeze the handles evenly until the terminal is properly compressed. For thin paper punchings or plastic parts, position the material in the narrow jaw and close the pliers to achieve the required deformation. Inspect each crimp visually to ensure a secure connection.

Recommendations

Use the pliers within the specified wire range (0.5–6 mm²) and avoid applying excessive force beyond normal crimping pressure. Keep the tool clean and free of debris; lubricate pivot points occasionally for smooth operation. Wear appropriate safety equipment when working on live circuits and follow relevant electrical safety procedures.
