PLANET ANT-OM5D-KIT antenna omnidirezionale dual band 4,5/7 dBi RP-SMA

An omni-directional dual band antenna that delivers 4.5 dBi gain on 2.4 GHz and 7 dBi on 5 GHz, ideal for expanding wireless coverage in indoor environments. Its 360° horizontal beamwidth ensures consistent signal distribution, making it a reliable choice for access points and routers requiring RP-SMA connectors.

Advantages

The ANT-OM5D-KIT combines dual band performance with a compact, screw-on design. It enhances signal strength and reduces dead zones, while the UV-resistant ABS housing ensures durability. Vertical polarization and low VSWR (<2.0) contribute to stable connections, and the wide operating temperature range (-20°C to 65°C) supports deployment in various indoor settings.

Suitable for

• Wireless access points and routers with RP-SMA connectors
• Indoor Wi-Fi coverage extension in offices, homes, and retail spaces
• Replacing stock antennas for improved range and reliability
• Dual band networks operating on 2.4 GHz and 5 GHz simultaneously

Key specifications

• Frequency: 2.4–2.5 GHz and 5.15–5.85 GHz
• Gain: 4.5 dBi (2.4 GHz), 7 dBi (5 GHz)
• VSWR: < 2.0
• Polarization: Vertical, Linear
• Horizontal beamwidth: 360°
• Vertical beamwidth: 35° (2.4 GHz), 25° (5 GHz)
• Impedance: 50 Ohm
• Connector: RP-SMA Plug (Male)
• Material: ABS, UV resistant
• Mounting: Direct screw-on
• Operating temperature: -20°C to 65°C
• Storage temperature: -30°C to 75°C
• Humidity: 5% to 95% (non-condensing)

Recommendations

For optimal performance, mount the antenna vertically and ensure clear line-of-sight to client devices. Pair with PLANET access points or routers featuring RP-SMA connectors to maximize coverage and reliability in dual band deployments.
