Presa di collegamento Rittal SZ 2500.600 VE5 3 poli 100-240V (MPN 2500600)

Rittal SZ 2500.600 VE5 is a 3‑pole connector socket designed for 100–240V mains applications. Intended for installation in industrial enclosures and control cabinets, this compact socket provides a standardized three‑pole power interface for equipment that requires a reliable AC connection within the common mains voltage range. The design focuses on space-saving installation and compatibility with typical electrical wiring in machinery and distribution cabinets.

Advantages

The connector socket offers a compact footprint and straightforward integration into electrical panels. Its three‑pole configuration supports stable AC power delivery across the stated voltage range and is compatible with common industrial wiring practices. The product is built to fit flush into enclosure cutouts, providing a secure and professional connection point while minimizing the need for additional adapters or converters.

Suitable for

Key specifications

How to use

Install the connector socket into the designated cutout in the enclosure or panel according to the enclosure manufacturer’s mounting dimensions. Ensure power is disconnected before wiring. Connect the incoming phase, neutral and protective conductor according to the site wiring standards and local electrical codes. Secure the socket in place and verify mechanical stability. After installation, restore power and test the connection with appropriate measurement tools to confirm correct voltage and continuity.

Recommendations

Use the socket only within its rated voltage range and in dry, protected enclosure interiors. Follow local electrical regulations for grounding and cable cross‑sections. Regularly inspect the connection for signs of wear, corrosion or loose contacts, and replace the socket if mechanical damage or electrical faults are found.
