Reely ingranaggio cilindrico in poliossimetilene modulo 0,5, 15 denti, foro 3 mm (SH0515HF)

The Reely SH0515HF spur gear is machined from polyacetal (POM), a material chosen for its low friction and high wear resistance. With a module of 0.5 and 15 teeth, it provides a precise 7.5 mm pitch diameter in compact drive systems.

Highlights

• Polyacetal (POM) construction for low friction and high wear resistance
• Module 0.5 tooth geometry for compatibility with other metric gears
• 15 teeth and 3 mm bore for direct shaft mounting
• Involute tooth profile with 20° pressure angle for smooth meshing

In daily use

This gear is intended for precision drive systems, model making, and robotics. Its dimensional stability helps maintain consistent performance under load, while the POM material reduces the need for lubrication in many setups.

Full specifications

• Gear type: Spur gear
• Material: Polyacetal (POM)
• Module: 0.5
• Number of teeth: 15
• Bore diameter: 3 mm
• Outer diameter: 8.5 mm
• Pitch diameter: 7.5 mm
• Pressure angle: 20°
• Tooth profile: Involute
• Gear standard: Metric
• Mounting type: Shaft mounting

Final note

Compatible with other Module 0.5 gears, the SH0515HF is a practical choice for custom gear trains.
