Rittal ventilatore filtrante 20 m³/h 230 V 50/60 Hz (3237108)

This filter fan delivers an unimpeded airflow of 20 m³/h, providing reliable ventilation for electrical enclosures. It operates on 230 V AC at 50/60 Hz and is designed for snap-on mounting with a spring-type terminal connection.

Advantages

Compact axial fan with ABS plastic housing in light grey (RAL 7035). IP54 protection with standard filter mat. Low power consumption of 10 W and noise level of 46 dB(A). Long service life of 60,000 hours at 20 °C.

Suitable for

• Ventilating small electrical enclosures
• Applications requiring IP54 protection
• Indoor use within -10 °C to +55 °C

Key specifications

• Airflow: 20 m³/h
• Rated voltage: 230 V AC
• Frequency: 50/60 Hz
• Rated current (50 Hz): 0.08 A
• Power consumption (50 Hz): 10 W
• Protection category: IP54 (with standard filter mat)
• Noise level (50 Hz): 46 dB(A)
• Installation cut-out: 92 x 92 mm
• External dimensions: 120 x 120 x 55 mm
• Operating temperature: -10 °C to +55 °C
• Housing material: ABS plastic
• Housing colour: RAL 7035 (light grey)
• Connection: Spring-type terminal
• Mounting: Snap-on
• Fan type: Axial
• Service life: 60,000 h at 20 °C

Recommendations

Use with a standard filter mat to maintain IP54 protection. Ensure the enclosure cut-out matches 92 x 92 mm for proper snap-on installation.
