Scheda adattatore interna USB Type-E Key B DELOCK 67346 — 2× USB-A 5 Gbit/s con staffa

DELOCK 67346 is an internal USB Type-E Key B adapter card that provides two external USB-A ports supporting transfer speeds up to 5 Gbps. The card connects to a compatible internal USB Type-E Key B header and includes a slot bracket for secure installation in a PC chassis, enabling straightforward expansion of external USB-A connectivity for desktops and workstations.

Advantages

This adapter card offers reliable high-speed USB-A connectivity without occupying external rear-panel space beyond the fitted slot bracket. It supports data transfer rates up to 5 Gbps, making it suitable for modern external storage and high-throughput peripherals. The compact internal interface and included mounting bracket simplify installation and reduce the need for internal cable routing changes.

Suitable for

• Adding external USB-A ports to desktop PCs and workstations
• Connecting external SSDs, HDDs and flash drives that require up to 5 Gbps throughput
• Attaching high-speed peripherals such as docking stations, card readers or webcams
• Upgrading systems with available internal USB Type-E Key B headers

Key specifications

• Interface: internal USB Type-E Key B connector
• Output: 2× external USB-A ports
• Maximum data transfer: up to 5 Gbps per port (USB 3.0/3.1 Gen1 speeds)
• Form factor: low-profile slot bracket for PC chassis mounting
• Compatibility: designed for motherboards with matching internal Type-E Key B header

How to use

Power down the PC and disconnect mains power before installation. Remove the appropriate expansion slot cover from the chassis, align the adapter’s slot bracket with the rear opening and secure it with the supplied screw. Connect the internal cable to the matching USB Type-E Key B header on the motherboard, ensuring proper orientation. Reassemble the case, power on the system and verify operation through the operating system’s device manager or USB port detection. No additional drivers are typically required for modern operating systems; if necessary, install manufacturer-provided drivers or updates.

Recommendations

For optimal performance, use quality USB-A cables and connect devices that support high-speed USB 3.x operation. Ensure the motherboard provides the required internal header and that chassis airflow is maintained around the expansion area to avoid overheating of connected high-performance peripherals.
