SCHROFF terminale angolare EMC per case 3U, alluminio, cromato chiaro, 128,4 mm, 24561198

Precision-machined from AlMgSi 0.5 aluminium with a clear chromated finish, this EMC corner profile end piece delivers reliable electrical contact for electromagnetic shielding in 3U enclosures. Its 12.5 × 12.5 mm cross-section and 128.4 mm length align with IEC 60297-3-101, ensuring seamless integration with Schroff EuropacPRO and RatiopacPRO frames.

Overview

The Schroff 24561198 is a dedicated EMC end piece that bridges the front panel or cover to the enclosure frame, creating a low-impedance path to suppress radiated emissions. The aluminium construction offers excellent conductivity and corrosion resistance, while the clear chromated passivation layer maintains long-term contact integrity. Screw-on mounting simplifies assembly and retrofit.

What stands out

• Optimized for 3U (133.35 mm) enclosure height per IEC 60297-3-101
• AlMgSi 0.5 aluminium body with clear chromated surface for reliable grounding
• Compact 12.5 mm square profile fits standard EMC gasket channels
• Compatible with EuropacPRO and RatiopacPRO series for flexible integration
• Enhances overall shielding effectiveness when paired with EMC gaskets

Technical details

• Product type: EMC corner profile end piece
• Material: Aluminium (AlMgSi 0.5)
• Surface finish: Clear chromated (passivated)
• Length: 128.4 mm
• Profile cross-section: 12.5 × 12.5 mm
• Enclosure height compatibility: 3U
• Mounting type: Screw-on
• Colour: Metallic grey
• RoHS compliant: Yes
• Packaging quantity: 1 piece

Our verdict

An essential accessory for achieving robust EMC performance in 3U Schroff enclosures. Its precision dimensions and conductive aluminium build make it a dependable choice for industrial and laboratory applications.
