Siemens fusibile cilindrico 16A 600V AC gG 10x38mm 3NC1016

Protect cables and lines in industrial applications with the Siemens 3NC1016 cylindrical fuse link. This 16 A, 600 V AC fuse link with gG operating class provides reliable overcurrent protection for general purpose use. Its 10 x 38 mm size fits standard fuse holders, and the ceramic body with silver-plated copper end caps ensures durability and low contact resistance.

Who is it for

Electrical engineers, panel builders, and maintenance technicians who need a dependable fuse for industrial control circuits, power distribution, and motor protection. Suitable for use in fuse holders compliant with IEC 60269-2.

Main features

• Rated current: 16 A
• Rated voltage: 600 V AC
• Operating class: gG (general purpose)
• Fuse size: 10 x 38 mm
• Breaking capacity: 120 kA
• Power loss: 1.5 W at rated current
• Body material: ceramic
• End cap material: silver-plated copper

Specifications

• Number of poles: 1
• Frequency: 50/60 Hz
• Ambient operating temperature: -20 to +50 °C
• Storage temperature: -50 to +80 °C
• Degree of protection: IP20 when installed in appropriate holder
• Standard compliance: IEC 60269-2

Tips

Always de-energize the circuit before replacing a fuse link. Verify that the fuse holder is rated for the same voltage and current. Keep spare fuse links in a dry, clean environment to maintain performance.
