Siemens SIMATIC ET 200SP AS-i Master F-Link modulo di comunicazione CM AS-i, 6ES7137-6AA01-0BA0

The Siemens CM AS-i module stands out by integrating safety monitoring directly into the AS-i master, eliminating the need for a separate safety controller in SIMATIC ET 200SP systems. This single-width module handles both standard and safety-related AS-i communication, reducing hardware footprint and simplifying wiring for distributed automation.

Highlights

• Integrated safety monitor for safe AS-i communication
• AS-Interface V3.0 with single address mode
• 12 bytes data width per module, 5 ms cycle time
• Hot-swappable via ET 200SP BaseUnit type A0
• Diagnostics for AS-i faults, short circuits, and overload

In daily use

Mounted on a DIN rail through an ET 200SP BaseUnit, the module connects to the backplane bus for power and PROFINET/PROFIBUS communication. The front AS-i port connects to the yellow AS-i cable, and configuration is done in TIA Portal. The integrated safety monitor enables safe communication with AS-i safety slaves, supporting functional safety without extra hardware. The module consumes a maximum of 100 mA from the 24 V DC backplane bus and operates from 0 to 60 °C, suitable for control cabinets with IP20 protection.

Full specifications

• Module type: AS-i Master F-Link Communication Module
• System compatibility: SIMATIC ET 200SP Distributed I/O System
• AS-Interface specification: V3.0
• Number of AS-i masters: 1
• Integrated safety monitor: Yes
• Addressing mode: Single address
• Data width: 12 bytes per module
• Cycle time: 5 ms
• Required BaseUnit type: BU-type A0
• Colour code: CC00
• Supply voltage: 24 V DC (via backplane bus)
• Current consumption (from backplane bus): max. 100 mA
• Degree of protection: IP20
• Operating temperature: 0 to 60 °C
• Communication interface: AS-Interface (front), PROFINET/PROFIBUS (via ET 200SP backplane)
• Configuration software: TIA Portal
• Diagnostics: AS-i fault, short circuit, overload
• Mounting type: DIN rail (via ET 200SP BaseUnit)
• Product family: SIMATIC ET 200SP

Final note

Engineered for seamless integration into SIMATIC ET 200SP, this module delivers reliable AS-i communication with built-in safety, ideal for compact machine automation.
