Supporto per soundbar Sonos Neomounts NM-USP100Schwarz - max 15 kg - installazione a schermo

The Neomounts NM-USP100BLACK soundbar mount is a universal bracket designed to attach a SONOS PLAYBAR or other soundbars to your existing TV bracket, wall or ceiling mount. Made from steel with a slim profile, the mount aligns the soundbar with the TV so audio follows the screen and allows adjustment of the sound angle. The product supports soundbars up to 15 kg and includes all necessary installation hardware.

Advantages

This Neomounts bracket offers a low-profile steel design that combines with most flat-screen wall or ceiling TV mounts. It is adjustable in width to cover VESA hole patterns on your TV bracket and permits rotation so the TV and Playbar can face the viewer together. The mount is lightweight yet sturdy, supports up to 15 kg, and comes with all installation materials for quick fitting.

Suitable for

• Attaching SONOS PLAYBAR to an existing TV bracket
• Mounting a soundbar to wall or ceiling-mounted flat screen TVs
• Situations requiring the soundbar to move with the TV for aligned audio

Key specifications

• Model: NM-USP100BLACK
• Material: Steel
• Maximum weight capacity: 15 kg
• Product weight: 1.01 kg
• Colour: Black
• Low profile from wall: 3 mm; Height: 45 mm
• Package quantity: 10 units (installation material included)

How to use

Fix the Neomounts bracket to the mounting points of your existing TV bracket according to the included instructions, using the supplied screws and fittings. Attach the soundbar to the bracket and adjust the width to match the VESA holes and the soundbar mounting points. Once secured, rotate and tilt the assembly as needed to align audio direction with the screen and achieve the desired listening angle.

Recommendations

Check the soundbar weight before installation to ensure it does not exceed the 15 kg limit. Mount on a compatible, properly installed TV bracket or a structurally sound wall/ceiling mount and follow included instructions and local building codes for safe installation.
