Supporto per TV Vogel's PFW 6850 165,1 cm (65 pollici) nero

The Vogel's PFW 6850 is an ultra-flat wall mount for displays up to 45 kg (100 lbs) and up to 165.1 cm (65"). It combines a slim profile with a swing-out arm that can be positioned to the left, right or center according to installation needs. The mount is made from lightweight aluminium, finished in black, and includes integrated cable management channels to protect power and signal cables when adjusting the display.

Advantages

The swing-out arm extends up to 76 cm from the wall and provides 15° downward tilt for flexible viewing angles. When retracted, the mount sits just 3.8 cm from the wall for a low-profile appearance. Its design supports secure attachment of TVs within the specified weight limit and offers smooth movement when pulling out or pushing in the display. Integrated cable channels keep cables tidy and protected during adjustment.

Suitable for

• Wall mounting a 65" (165.1 cm) TV or similar flat-panel display up to 45 kg
• Rooms where adjustable viewing angles are needed (living rooms, conference rooms, classrooms)
• Installations requiring a low-profile mount with occasional swing-out access

Key specifications

• Maximum load: 45 kg (100 lbs)
• Screen size compatibility: up to 165.1 cm (65")
• Maximum extension: 76 cm from the wall
• Tilt: 15° downward
• Retracted depth: 3.8 cm from the wall
• Material: lightweight aluminium
• Finish: black
• MPN: 73201901
• EAN: 8712285323362

How to use

Fix the wall plate to a suitable load-bearing wall following the mounting instructions and local building standards. Attach the bracket to the TV using compatible VESA mounting points and the appropriate screws. Hang the TV on the wall plate and secure it according to the manual. Use the swing-arm to position the display left, right or center as required, extend up to 76 cm for access or viewing, and adjust the 15° downward tilt to achieve the preferred angle. Route cables through the built-in channels to prevent pinching when moving the arm.
