Synergy 21 serie LED EOS 07 controller DALI 2.4G modulo Bluetooth to DALI

The Synergy 21 LED Serie EOS 07 DALI Controller is a Bluetooth to DALI gateway module that enables wireless control of DALI lighting systems via a smartphone app. It supports dimming, switching, color control (DT8), scene recall, and timer functions, making it ideal for modern lighting installations.

Advantages

Wireless control via Bluetooth Low Energy (BLE) 2.4 GHz; easy integration with existing DALI systems; supports up to 64 DALI devices and 16 groups/scenes; compact design for built-in or surface mounting.

Suitable for

• Commercial lighting control
• Smart building automation
• Retrofit DALI installations

Key specifications

• Product Type: DALI Bluetooth Gateway Module
• Control Interface: Bluetooth Low Energy (BLE) 2.4 GHz
• Lighting Protocol: DALI (IEC 62386)
• Power Supply: DALI Bus Powered
• DALI Channels: 1
• Max DALI Devices: 64
• Max DALI Groups: 16
• Max DALI Scenes: 16
• Bluetooth Range: Up to 30m (line of sight)
• Operating Temperature: -20°C to +50°C
• Protection Class: IP20
• Mounting Type: Built-in / Surface Mount
• Housing Material: Plastic
• Color: White
• App Control: Yes
• Functions: Dimming, Switching, Color Control (DT8), Scene Recall, Timer

Recommendations

For optimal performance, ensure DALI bus power is within specifications and Bluetooth range is not obstructed by heavy walls.
