Telegärtner H02025A0543 modulo Keystone RJ45 Cat.6A schermato, senza attrezzi, argento/nero

The Telegärtner H02025A0543 is a high-performance Cat.6A shielded RJ45 keystone jack designed for reliable 10 Gigabit Ethernet transmission. This tool-free, IDC termination module ensures quick and secure installation without special tools, making it ideal for structured cabling in enterprise networks, data centers, and industrial environments. With robust die-cast zinc shielding and gold-plated contacts, it delivers excellent EMI protection and long-term durability.

Advantages

Tool-free termination reduces installation time and labor costs. Shielded design minimizes electromagnetic interference for stable data transmission. Universal wiring scheme supports both T568A and T568B standards. Compatible with PoE, PoE+, and 4PPoE for power-over-ethernet applications. GHMT PVP certified and UL listed for quality assurance.

Suitable for

• Enterprise network infrastructure
• Data center cabling
• Industrial Ethernet installations
• Smart building and IoT deployments

Key specifications

• Connector Type: RJ45 Jack
• Category: Cat.6A (ISO/IEC 11801, EN 50173-1, TIA/EIA-568-C.2)
• Shielding: Shielded (STP)
• Termination Type: IDC, Tool-Free
• Mounting Type: Keystone (19.35 x 14.8 mm cutout)
• Transmission Performance: 10 Gigabit Ethernet (10GBASE-T)
• Frequency Range: Up to 500 MHz
• PoE Compatibility: PoE, PoE+, 4PPoE (IEEE 802.3af/at/bt)
• Housing Material: Die-cast zinc (shielding), Plastic (housing)
• Contact Material: Phosphor bronze, gold-plated (min. 0.8 µm)
• Number of Ports: 1
• Insertion Cycles: ≥ 750
• Operating Temperature: -40 °C to +70 °C
• Certifications: GHMT PVP certified, UL listed
• Cable Diameter Range: 6.0 - 9.0 mm
• Wire Gauge Compatibility: AWG 24/1 - 22/1 (solid), AWG 26/7 - 22/7 (stranded)
• Color: Silver / Black

Recommendations

For optimal performance, use with Cat.6A shielded patch cables and ensure proper grounding. Suitable for high-density patch panels and wall outlets.
