TELEGÄRTNER tappo di protezione SMA, oro, avvitabile, ottone, per connettore maschio SMA H00040A0001

Protective cap for SMA connectors, providing dust and mechanical protection for unused male SMA ports. The screw-on design ensures a secure fit, while the gold-plated brass construction offers durability and corrosion resistance.

Advantages

Gold plating provides excellent conductivity and resistance to oxidation, maintaining signal integrity when the cap is in place. The brass body offers robust mechanical protection against impacts and environmental factors.

Suitable for

• Protecting unused male SMA connectors on RF equipment
• Preventing dust ingress in laboratory and field environments
• Maintaining connector cleanliness during storage or transport

Key specifications

• Connector type: SMA
• Connector gender (cap interface): Female (screws onto male SMA)
• Material: Brass
• Plating: Gold
• Mounting type: Screw-on
• Impedance compatibility: 50 Ohm
• Operating temperature range: -65°C to +165°C
• Thread size (internal): 1/4-36 UNS-2B

Recommendations

Ideal for RF engineers and technicians who need to protect SMA ports from contamination when not in use. The gold finish also makes it easy to identify protected ports at a glance.
