Wera 8790 A VDE bussola isolata attacco 1/4" 8 mm 05005929001

Electricians working on live circuits need tools that protect them from electrical shock. The Wera 8790 A VDE insulated socket is designed for safe use on live parts up to 1000 V AC and 1500 V DC. Its 1/4" square drive fits standard ratchets and extensions, while the 8 mm hexagonal profile grips fasteners securely.

Key specifications

• Drive size: 1/4 inch (6.3 mm)
• Socket size: 8.0 mm
• Insulation standard: VDE (IEC 60900)
• Maximum voltage rating: 1000 V AC / 1500 V DC
• Material: Chrome Vanadium Steel
• Finish: Chrome-plated, fully insulated
• Socket profile: Hexagonal (6-point)
• Overall length: 48 mm
• Outer diameter (max): 18 mm
• Insulation colour: Red/Yellow
• Certification: GS Mark (TÜV Rheinland), VDE

Why choose it

The socket is individually tested for dielectric strength, ensuring reliable insulation. Its chrome vanadium steel construction provides durability, while the red/yellow insulation is highly visible for safety. It is compatible with Wera Zyklop ratchets and extensions, making it a versatile addition to your tool kit.

Ideal use cases

• Electrical installations and maintenance
• Working on live parts up to 1000 V AC
• Use with Wera Zyklop ratchets and extensions

Good to know

This socket is a single piece, hand tool accessory. It is certified by VDE and carries the GS Mark from TÜV Rheinland, confirming its safety and quality.
