ACT cavo patch in fibra ottica MTRJ-SC 9/125µm OS1 duplex 1 m bianco (RL5901)

Single-mode OS1 fiber optic patch cable with MTRJ to SC connectors, 9/125µm core/cladding, duplex, 1 meter, white PVC jacket. Ideal for LAN, data centers, and telecommunications.

Overview

The ACT RL5901 is a single-mode duplex fiber optic patch cable featuring an MTRJ connector on one end and an SC connector on the other. With a 9/125µm core/cladding diameter and OS1 standard, it delivers reliable performance for high-speed data transmission over long distances. The 1-meter white PVC jacket cable is suitable for indoor use in patch panels, switches, and media converters.

What stands out

• MTRJ to SC duplex connectors for versatile connectivity
• Single-mode OS1 fiber supports 1310nm and 1550nm wavelengths
• Low insertion loss of ≤0.3 dB and high return loss of ≥50 dB
• Durable white PVC jacket for easy identification and protection

Technical details

• Connector Type A: MTRJ
• Connector Type B: SC
• Fiber Mode: Single-mode
• Fiber Core/Cladding Diameter: 9/125 µm
• Fiber Standard: OS1
• Cable Structure: Duplex
• Number of Fibers: 2
• Cable Length: 1 m
• Cable Color: White
• Connector Polishing Type: UPC
• Jacket Material: PVC
• Insertion Loss (Max): 0.3 dB
• Return Loss (Min): 50 dB
• Operating Wavelengths: 1310 nm, 1550 nm

Our verdict

A reliable single-mode patch cable for professional network installations, offering low loss and stable performance in a compact 1-meter length.
