ALLNET ALL-BRICK-0447 iniettore PoE passivo 48V 0,9A 43,2W Gigabit Ethernet

The ALLNET ALL-BRICK-0447 is a high-performance Passive PoE Injector designed to deliver reliable power and data over a single Ethernet cable. With 48V DC output and up to 43.2W power, it is ideal for powering PoE-compatible devices such as IP cameras, wireless access points, and VoIP phones. This injector supports Gigabit Ethernet (10/100/1000 Mbps) and features two RJ45 ports: one for data input and one for combined data and power output. Its compact desktop design and durable plastic housing make it suitable for home or office environments.

Advantages

The ALL-BRICK-0447 offers a cost-effective solution for extending network connectivity to devices that require both data and power. It supports passive PoE with 48V output, ensuring compatibility with a wide range of devices. The unit includes protection features such as over-voltage, over-current, and short-circuit protection, safeguarding your equipment. With LED indicators for power and link/activity, monitoring network status is straightforward.

Suitable for

• Powering IP cameras, wireless access points, and VoIP phones
• Extending network reach in small offices or home networks
• Applications requiring reliable PoE without a PoE switch

Key specifications

• Brand: ALLNET
• Model: ALL-BRICK-0447
• MPN: ALL-BRICK-0447
• EAN: 4038816130136
• Category: PoE Injector
• PoE Output Voltage: 48V DC
• PoE Output Current: 0.9A
• Max. PoE Output Power: 43.2W
• PoE Standard: Passive PoE (48V)
• Data Rate: 10/100/1000 Mbps (Gigabit Ethernet)
• Ethernet Ports: 2 (1x Data In, 1x Data + Power Out)
• Input Voltage: 100-240V AC
• Input Frequency: 50/60 Hz
• Power Pin Assignment: 4,5(+) / 7,8(-)
• LED Indicators: Power, Link/Activity
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 10% to 90% non-condensing
• Housing Material: Plastic
• Protection Features: Over-voltage, Over-current, Short-circuit
• Power Connector (Input): IEC C14
• Mounting Type: Desktop
• Compliance: CE, FCC

Recommendations

For optimal performance, use with devices that support passive PoE 48V. Ensure the total power consumption of the connected device does not exceed 43.2W. This injector is not compatible with IEEE 802.3af/at/bt standards; it provides passive PoE only.
