BCS BCS-V-AS videocitofono esterno, 2 fili, 720p HD, argento

Secure your entrance with the BCS-V-AS outdoor video intercom station, built for BCS 2-wire systems. This rugged unit delivers crisp 720p HD video and clear two-way audio, making it ideal for front doors, gates, and building entrances. Its aluminum alloy housing and IP65 rating ensure reliable performance in rain, dust, and extreme temperatures.

Key specifications

• System type: 2-wire video intercom
• Camera sensor: 1/3" CMOS
• Resolution: 720p HD
• Viewing angle: 110° horizontal
• Night vision: IR LEDs up to 3 m
• Audio: two-way full-duplex with built-in microphone and speaker
• Door unlock: 1 relay output (NO/NC)
• Installation: surface mount
• Housing: aluminum alloy
• Protection: IP65 (dust-tight, water jets)
• Impact resistance: IK07
• Operating temperature: -30°C to +50°C
• Power: DC 24V via 2-wire bus
• Call buttons: 1 with white LED backlight
• Compatibility: BCS 2-wire system monitors

Why choose it

Built for demanding outdoor environments, the BCS-V-AS combines high-definition imaging, reliable audio, and a robust enclosure. The wide 110° lens ensures you see visitors clearly, while the IR cut filter and LEDs provide round-the-clock monitoring. A single relay output allows you to control electric strikes or magnetic locks directly from the station. Its compact surface-mount design simplifies installation, and the aluminum housing resists corrosion and impact.

Ideal use cases

• Single-family home entrances
• Multi-tenant buildings and apartment gates
• Office or warehouse access points
• Garage or service entrances

Good to know

The station connects directly to your BCS 2-wire system, providing power and communication over a single cable. No additional power supply is needed. The white LED backlight on the call button ensures visibility at night. For enhanced security, the relay output can be configured for normally open or normally closed operation.
