BCS lettore di codici a barre laser 1D RS-232 a montaggio fisso IP65 nero

The BCS-L-KKD-D424D(2) is a high-performance fixed-mount laser barcode scanner designed for industrial and commercial environments. With its rugged aluminum housing and IP65 rating, it withstands dust, moisture, and demanding conditions. This 1D scanner delivers fast and accurate reading of linear barcodes at up to 500 scans per second, making it ideal for automated identification in manufacturing, logistics, and retail.

Advantages

Reliable laser scanning technology ensures consistent performance even on damaged or poorly printed barcodes. The RS-232 interface provides seamless integration with legacy systems and industrial controllers. Its compact fixed-mount design saves space and allows for hands-free operation, increasing throughput. The IP65 protection guarantees longevity in harsh environments.

Suitable for

• Automated production lines and conveyor systems
• Warehouse and logistics sorting stations
• Retail point-of-sale (POS) fixed installations
• Medical and laboratory equipment tracking
• Document and asset management

Key specifications

• Scanning Technology: Laser (650 nm visible diode)
• Decoding Capability: 1D linear barcodes (Code 39, Code 128, EAN/UPC, Interleaved 2 of 5, Codabar, etc.)
• Scan Rate: 500 scans/second
• Reading Distance: 50 - 300 mm
• Minimum Resolution: 0.15 mm (6 mil)
• Interface: RS-232 (9-pin D-sub female)
• Input Voltage: 5 - 30 VDC
• Current Consumption: Max 100 mA
• IP Rating: IP65
• Operating Temperature: 0 to 50 °C
• Housing Material: Aluminum
• Cable Length: 2.5 m

Recommendations

For optimal performance, ensure the scanner is mounted at the recommended reading distance and angle. Use a regulated power supply within the specified voltage range. The RS-232 cable can be extended up to 15 m with proper shielding. Regular cleaning of the scan window with a soft cloth will maintain reading accuracy.
