BlueOptics AdTran 1200484G3 BlueLAN 10GBASE-CR SFP+ a SFP+ cavo Direct Attach passivo compatibile, 3M, AWG30 (1200484G3-BL)

The BlueOptics 1200484G3-BL is a high-performance, passive Direct Attach Cable (DAC) designed for 10 Gigabit Ethernet connectivity. This cable is fully compatible with AdTran 1200484G3 equipment and provides a cost-effective, low-latency solution for short-range interconnects in data centers, server rooms, and storage area networks.

Advantages

This BlueLAN DAC cable offers reliable 10GBASE-CR performance with minimal power consumption (<0.1W) and low signal loss. The passive twinax copper design ensures zero latency and is hot-swappable for easy installation. With a length of 3 meters and AWG30 gauge, it is ideal for rack-to-rack or server-to-switch connections.

Suitable for

• Data center interconnects
• Server-to-switch connections
• Storage Area Networks (SAN)
• High-performance computing environments

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Cable Type: Copper Twinax
• Data Rate: 10 Gbps
• Ethernet Standard: 10GBASE-CR
• Cable Length: 3 meters
• Connector Type (End A): SFP+
• Connector Type (End B): SFP+
• Cable Gauge: AWG30
• Cable Design: Passive
• Compatibility: AdTran 1200484G3
• Hot-Swappable: Yes
• Protocol Support: Ethernet, Fibre Channel, InfiniBand
• Impedance: 100 Ohm
• Compliance: SFF-8431, SFF-8432, RoHS
• Power Consumption: <0.1W
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C

Recommendations

For optimal performance, use this cable with compatible SFP+ ports on switches, routers, and servers. Ensure proper cable management to avoid bending beyond the minimum bend radius. This cable is a direct replacement for the AdTran 1200484G3 and is backed by BlueOptics quality assurance.
