BlueOptics Attenuatore fibra ottica monomodale LC/APC simplex 20 dB

The BlueOptics SFA21BM20 is a high-quality fiber optic attenuator designed for singlemode networks. It provides a precise 20 dB attenuation to optimize signal levels and prevent receiver overload in telecommunications, data centers, FTTx, LAN, and CATV applications. The LC/APC connector ensures low insertion loss and high return loss, making it ideal for high-performance optical systems.

Advantages

This attenuator offers reliable and stable attenuation with a tolerance of ±0.5 dB, ensuring consistent performance. The APC polish minimizes back reflection, and the durable metal alloy housing with zirconia ceramic ferrule guarantees long-term reliability over 500 mating cycles. It is RoHS and CE compliant, meeting industry standards for safety and environmental responsibility.

Suitable for

• Telecommunications networks
• Data centers
• FTTx installations
• Local Area Networks (LAN)
• CATV systems

Key specifications

• Attenuation: 20 dB
• Connector: LC/APC Simplex (Male-Female)
• Fiber mode: Singlemode
• Return loss: ≥ 60 dB
• Wavelength range: 1260 nm - 1650 nm
• Attenuation tolerance: ± 0.5 dB
• Polarization dependent loss: ≤ 0.2 dB
• Maximum optical power: 200 mW (23 dBm)
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +85°C
• Durability: > 500 mating cycles
• Ferrule material: Zirconia ceramic
• Housing material: Metal alloy
• Compliance: RoHS, CE

Recommendations

For optimal performance, use this attenuator in singlemode fiber links where precise signal reduction is required. Ensure connectors are clean before mating to maintain low insertion loss and high return loss.
