BlueOptics Dell 98T8D compatibile BlueLAN 25GBASE-CR passivo SFP28 a SFP28 Direct Attach cavo, 0,5 m, AWG30

The BlueOptics Dell 98T8D compatible BlueLAN DAC SFP28 cable is a high-performance, passive direct attach cable designed for 25 Gigabit Ethernet connections. With a length of 0.5 meters and AWG30 gauge, it provides a reliable, low-latency link between SFP28 ports in data centers and enterprise networks.

Advantages

This cable offers a cost-effective, plug-and-play solution for short-range 25G connections. Its passive design ensures zero power consumption, while the copper twinax construction delivers excellent signal integrity. Fully compatible with Dell 98T8D interfaces, it simplifies deployment and reduces cabling complexity.

Suitable for

• Data center top-of-rack and server-to-switch connections
• High-performance computing clusters
• Enterprise networking environments requiring 25GBASE-CR

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Cable Type: Copper Twinax
• Length: 0.5 meters (1.64 ft)
• Data Rate: 25 Gbps
• Ethernet Standard: 25GBASE-CR
• Connectors: SFP28 to SFP28
• Design: Passive
• Wire Gauge: AWG30
• Impedance: 100 Ohm
• Hot-Swappable: Yes
• Power Consumption: < 0.1W
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Compliance: RoHS
• Jacket Material: PVC

Recommendations

For optimal performance, ensure your equipment supports SFP28 interfaces and 25GBASE-CR. This cable is ideal for short-distance, high-speed interconnects within racks or adjacent racks.
