BLUEOPTICS Finaris FTLX1772M3BCL ricetrasmettitore SFP+ compatibile BO35J13640D

The BLUEOPTICS Finaris FTLX1772M3BCL compatible SFP+ transceiver (BO35J13640D) is a high-performance, hot-pluggable module designed for 10 Gigabit Ethernet applications. It operates at 10 Gbps over multi-mode fiber (MMF) with a reach of up to 220 meters on OM3 fiber. This transceiver is fully compliant with the SFP+ MSA and is a cost-effective alternative to the original Finaris FTLX1772M3BCL.

Advantages

This transceiver offers reliable performance with low power consumption (<1.0 W) and supports Digital Diagnostic Monitoring (DDM/DOM) for real-time monitoring of operating parameters. It is hot-pluggable, making installation and maintenance easy without network downtime.

Suitable for

• 10 Gigabit Ethernet (10GbE) networks
• Data centers and enterprise networks
• Metro and access networks
• High-speed storage area networks (SAN)

Key specifications

• Transceiver Type: SFP+
• Data Rate: 10 Gbps
• Protocol: 10GBASE-LRM
• Wavelength: 1310 nm
• Max Distance: 220 m (OM3 MMF)
• Fiber Type: Multi-Mode Fiber (MMF)
• Connector Type: LC Duplex
• DDM/DOM Support: Yes
• Hot-Pluggable: Yes
• Operating Temperature: 0°C to 70°C
• Power Consumption: <1.0 W
• Power Supply: 3.3 V
• Laser Type: DFB
• RoHS Compliant: Yes

Recommendations

This transceiver is ideal for upgrading your network to 10 Gbps speeds while maintaining compatibility with existing MMF infrastructure. Ensure your switch or router supports SFP+ modules and 10GBASE-LRM standard.
