BlueOptics Juniper 720-087756 cavo Direct Attach Copper (DAC) BlueLAN compatibile - passivo 400G QSFP-DD su QSFP-DD, 1m

The BlueOptics BlueLAN BL292901X1M26 is a high-performance Direct Attach Copper (DAC) cable designed for seamless integration with Juniper 720-087756 compatible networking equipment. This passive 400 Gigabit Ethernet cable features QSFP-DD connectors on both ends, enabling reliable, low-latency connections within racks or across adjacent racks in data centers and enterprise networks.

Advantages

Engineered for maximum signal integrity and minimal power consumption (<0.1W), this twinaxial copper cable supports 400GBASE-CR8 standards and is hot-swappable for easy deployment. Its 26 AWG wire gauge and PVC jacket ensure durability and flexibility, while compliance with RoHS, CE, FCC, and SFF-8636 guarantees industry-standard quality.

Suitable for

• Data center interconnect (DCI) for high-speed server-to-switch or switch-to-switch links
• High-performance computing (HPC) clusters requiring low-latency, high-bandwidth connections
• Enterprise networking upgrades to 400G infrastructure

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Cable Type: Twinaxial Copper
• Data Rate: 400 Gigabit Ethernet (400G)
• Connector Type A: QSFP-DD
• Connector Type B: QSFP-DD
• Cable Length: 1 Meter
• Active/Passive: Passive
• Compatibility: Juniper 720-087756
• Protocol Support: IEEE 802.3cd (400GBASE-CR8), Ethernet, InfiniBand
• Impedance: 100 Ohm
• Wire Gauge (AWG): 26 AWG
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Power Consumption: <0.1W
• Hot-Swappable: Yes
• Jacket Material: PVC
• Compliance: RoHS, CE, FCC, SFF-8636
• Data Lanes: 8x 50Gb/s PAM4

Recommendations

For optimal performance, pair this BlueLAN DAC cable with compatible Juniper 720-087756 switches or network interface cards. Ensure proper handling and storage within specified temperature ranges to maintain signal quality.
