BlueOptics Ricetrasmettitore QSFP28 100GBASE-LR4 compatibile con Finisar FTL4C1QL2L

The BlueOptics BO25K13602D is a high-performance QSFP28 optical transceiver designed for 100 Gigabit Ethernet applications. Fully compatible with Finisar FTL4C1QL2L, this module delivers reliable connectivity for data centers, enterprise networking, and telecommunications. It supports 100GBASE-LR4 standard over single-mode fiber with a reach of up to 10 km.

Advantages

Cost-effective alternative to OEM modules without compromising performance. Hot-pluggable design ensures easy installation and minimal downtime. Low power consumption under 3.5 W reduces operational costs. Digital Diagnostics Monitoring (DDM) provides real-time performance tracking.

Suitable for

• Data center interconnects
• Enterprise network backbone
• Telecommunications infrastructure
• 100 Gigabit Ethernet links

Key specifications

• Form Factor: QSFP28
• Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-LR4
• Wavelength: 1310 nm (4x25G LAN WDM)
• Max Distance: 10 km
• Fiber Type: Single-Mode (SMF)
• Connector: Duplex LC
• Power Consumption: < 3.5 W
• Operating Temperature: 0°C to 70°C
• Compliance: MSA, RoHS, CE, FCC

Recommendations

For optimal performance, use with single-mode fiber patch cables and ensure proper cleaning of optical connectors. This transceiver is ideal for upgrading existing 10G/40G networks to 100G.
