Cavo in fibra ottica InfiniBand BlueOptics SFP5142FU5MKB 5 m MPO 4x SC

The BlueOptics SFP5142FU5MKB InfiniBand fibre optic cable is a 5 m multimode OM4 breakout cable with an MPO (MTP-style) 8‑fibre connector on one end and four duplex SC connectors on the other. Designed for InfiniBand and high-speed data centre links, it uses 50 µm core fibres (G50/125 µm) and supports full duplex transmission at wavelengths around 850 nm. The cable features an LSZH (Low Smoke Zero Halogen) jacket and an 8‑fibre pinout suitable for QSFP deployments, providing a compact, pre-terminated alternative to splicing.

Advantages

The cable provides a factory-terminated MPO to 4x SC breakout that speeds up installation and avoids field splicing and specialized tooling. As an OM4 multimode variant it delivers low insertion loss and high return loss suitable for short-reach, high-bandwidth links in data centres and SAN environments. The LSZH sheath reduces smoke and halogen emissions in case of fire and the precision ceramic ferrules used in the connectors ensure consistent mating performance and long connector life.

Suitable for

Key specifications

How to use

Connect the MPO end to an MPO port, cassette or QSFP breakout module and plug the four SC duplex connectors into the corresponding SC ports or patch panel adapters. Ensure correct alignment of the MPO key and verify that each SC pair maps to the intended lane according to the 1–4 & 9–12 pinout. No splicing is required; the pre-terminated cable is ready for immediate deployment after visual inspection and standard cleaning of connector endfaces.

Recommendations

Before installation, inspect and clean connector endfaces with appropriate fibre cleaning tools and follow site cable management practices to avoid tight bends or excessive tensile stress. Use MPO cassettes or labelled patch panels to maintain lane mapping and simplify troubleshooting. For critical links, verify insertion loss and continuity with suitable test equipment after installation and keep the factory measurement protocol for reference.
