Cavo in fibra ottica MTP EFB Elektronik MTPF12MTPFOM4-5 — OM4, 50 µm, 5 m, MTP–MTP, viola

The EFB Elektronik MTPF12MTPFOM4-5 is a 5 m multimode fibre optic cable with MTP connectors on both ends, designed for high-density and high-speed optical links. Using OM4 multimode fibre with a 50 µm core diameter, this violet cable supports low-loss transmission over short to medium distances and is suitable for InfiniBand, Ethernet and other multimode optical networks. The compact MTP–MTP configuration allows easy integration into patch panels, cassette systems and direct switch-to-switch connections in data centre racks.

Advantages

This OM4 MTP–MTP cable provides increased bandwidth and lower attenuation compared with lower-grade multimode fibres, helping to maintain signal integrity for high-speed links. The 12-fibre MTP connector configuration enables parallel optics use and high-density cabling, reducing patching space and simplifying routing in crowded rack environments. The 5 m length offers a balance between flexibility and structured cabling requirements for typical data centre layouts.

Suitable for

• Data centre interconnects and top-of-rack to end-of-row links
• High-speed InfiniBand and multimode Ethernet connections
• High-density patch panels, cassettes and MTP trunking
• Parallel optics transceiver connections (e.g., 40G/100G implementations)
• Switch-to-switch and equipment-to-equipment short to medium reach links

Key specifications

• Fibre type: OM4 multimode
• Core diameter: 50 µm
• Connector type: MTP to MTP (12-fibre MPO-style)
• Cable length: 5 m
• Colour: violet
• Application: multimode parallel optics and trunking

How to use

Install the MTP–MTP cable by aligning the keyed MTP connectors with the respective sockets on transceivers, patch panels or cassettes and insert until the connector latches. Ensure the connector orientation matches the polarity requirements of your system and that both ends are clean before mating. Route the cable through cable management paths, avoiding tight bends and excessive pulling force; observe the manufacturer-recommended minimum bend radius to preserve fibre performance. For deployment in high-density racks, label each end to maintain clear identification and polarity during installation and maintenance.

Recommendations

Inspect and clean connector endfaces with appropriate fibre cleaning tools before every connection. Use dust caps when connectors are not in use, avoid sharp bends, and follow proper polarity mapping for parallel optics to ensure correct channel alignment and optimal link performance.
