Cavo patch Kabelmeister Cat.7 S/FTP, guaina TPE, senza alogeni, magenta, 0,15 m

When rack space is at a premium and every bend counts, this ultra-short 0.15 m patch cable from Kabelmeister delivers the flexibility that rigid PVC alternatives simply cannot match. The thermoplastic elastomer (TPE) jacket stays supple even in tight turns, making it the go-to choice for patching adjacent ports in high-density server cabinets or linking devices in confined enclosures. Its vivid magenta colour provides instant visual identification, cutting troubleshooting time in complex installations. Built on a Cat.7 raw cable with S/FTP shielding, it guarantees 10 Gigabit performance over short links while keeping alien crosstalk firmly under control.

Highlights

• Cat.7 S/FTP shielding: each pair individually foil-wrapped plus overall braid for superior noise immunity
• Highly flexible TPE jacket: bends easily without damage, perfect for tight spaces and frequent re-patching
• Halogen-free (LSZH): emits low smoke and no toxic halogens in case of fire, safer for enclosed spaces
• Gold-plated contacts (50µ): ensure consistent signal integrity and corrosion resistance over many mating cycles
• Backward compatible: works seamlessly with Cat.6a, Cat.6, Cat.5e, and Cat.5 networks

In daily use

Imagine a server cabinet where every centimetre counts: this cable bridges the gap between a patch panel and a switch without leaving excess slack that blocks airflow or creates clutter. The magenta colour lets you quickly trace connections, reducing troubleshooting time. Its halogen-free jacket adds peace of mind in environments where fire safety is critical, while the stranded copper conductors maintain reliable 10GBASE-T transmission over short distances.

Full specifications

• Cable type: RJ45 patch cable, Cat.7
• Shielding: S/FTP (PiMF – pairs in metal foil, overall braided shield)
• Connectors: RJ45 male to RJ45 male, gold-plated contacts (50µ)
• Jacket material: TPE (thermoplastic elastomer), halogen-free, highly flexible
• Colour: Magenta
• Length: 0.15 m (15 cm)
• Conductor: Copper, AWG 26/7 stranded
• Bandwidth: Up to 600 MHz
• Data transfer rate: Up to 10 Gbps (10GBASE-T)
• Wiring standard: TIA/EIA 568B
• Flammability rating: LSZH (Low Smoke Zero Halogen)
• Standards compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Application: LAN, network, Ethernet

Final note

For installers who demand both performance and manageability in dense networking environments, this Kabelmeister patch cable offers the ideal blend of flexibility, safety, and speed.
