Connettore per cavo EFB Elektronik 29061.1 D-Sub 15 poli nero

The EFB Elektronik 29061.1 Dsub 15-pin wire connector in black is a compact male connector designed for reliable signal and low-voltage connections in electronic equipment. It meets RoHS requirements for restricted hazardous substances. With small external dimensions (39.1 mm wide, 12.6 mm deep, 20.8 mm high) and a single-piece pack format, the connector is suited for repair work, prototyping and tight-space installations where a standard D-sub 15-pin interface is required.

Advantages

This D-sub 15-pin connector provides a standard male interface in a compact housing that simplifies cable termination and panel mating. Compliance with RoHS ensures reduced hazardous materials while the black finish offers a neutral appearance for a variety of equipment. The small footprint makes it easier to fit into constrained enclosures or on custom adapters without compromising on the established D-sub pin layout.

Suitable for

• Cable assemblies and repairs for older video, control or measurement equipment
• Prototyping and custom cable harnesses requiring a D-sub 15-pin male connector
• Retrofit and replacement of worn or damaged D-sub interfaces in compact enclosures

Key specifications

• Connector type: D-sub 15-pin, male
• Color: Black
• Compliance: RoHS
• Dimensions (W × D × H): 39.1 mm × 12.6 mm × 20.8 mm
• Pack quantity: 1 piece

How to use

Prepare the cable by stripping the outer jacket and individual conductor insulation to the recommended lengths for the chosen solder or crimp termination method. Install the connector onto the cable according to standard D-sub wiring diagrams, ensuring correct pin assignment and secure mechanical fixing. After assembly, verify continuity and absence of short circuits with a multimeter before final installation into the mating socket or panel.

Recommendations

Use strain relief and proper shielding practices where necessary to maintain signal integrity. For mounted installations, ensure mating screws or retention hardware are tightened to the device manufacturer's recommended torque to avoid loose connections. Store unused connectors in a dry environment away from direct sunlight.
